N3H-X8US 8KW Split Phase Hybrid Solar Inverter
120/240V Split Phase Hybrid Inverter
| Technical Data | N3H-X8US | |||
| PV Input Data | ||||
| MAX.DC Kupinza Simba | 12KW | |||
| Nhamba yeMPPT Trackers | 4 | |||
| MPPT Range | 120 - 430V | |||
| MAX.DC Input Voltage | 500V | |||
| MAX.Input Current | 14A×4 | |||
| Battery Input Data | ||||
| Nominal Voltage (Vdc) | 48V | |||
| MAX.Charging/Dicharging Current | 190A/190A | |||
| Battery Voltage Range | 40-60V | |||
| Bhatiri Type | Lithium uye Lead Acid Battery | |||
| Kuchaja Strategy yeLi-Ion Battery | Kuzvigadzirisa kune BMS | |||
| AC Output Data(PaGridhi) | ||||
| Nominal Output Power Output kune Grid | 8KVA | |||
| MAX. Inooneka Simba rekubuda kune Grid | 8.8KVA | |||
| Output Voltage Range | 110-120V/220-240V chikamu chekupatsanurwa, 208V(2/3 chikamu), 230V(1 chikamu) | |||
| Output Frequency | 50/60Hz (45 kusvika 54.9Hz / 55 kusvika 65Hz) | |||
| Nominal AC Current Output kune Grid | 33.3A | |||
| Max.AC Yazvino Kubuda kuGridhi | 36.7A | |||
| Zvakabuda THDI | <2% | |||
| AC Output Data (Back-Up) | ||||
| Nominal. Inooneka Power Output | 8KVA | |||
| MAX. Inooneka Power Output | 8.8KVA | |||
| Nominal Output Voltage LN/L1-L2 | 120/240V | |||
| Nominal Output Frequency | 60Hz | |||
| Output Power Factor | 0.8 inotungamira ...0.8lagging | |||
| Zvakabuda THDU | <2% | |||
| Kubudirira | ||||
| Europe Kubudirira | >=97.8% | |||
| MAX. Bhatiri rekutakura Kushanda | =97.2% | |||
| Dziviriro | ||||
| Grounding Detection | EHE | |||
| Arc Mhosva Dziviriro | EHE | |||
| Island Protection | EHE | |||
| Battery Reverse Polarity | EHE | |||
| Insulation Resistor Detection | EHE | |||
| Residual Current Monitoring Unit | EHE | |||
| Output Over Current Protection | EHE | |||
| Back-up Output Pfupi Dziviriro | EHE | |||
| Terminal Temperature Detection | EHE | |||
| Output Over Voltage Protection | EHE | |||
| Output Under Voltage Protection | EHE | |||
| General Data | ||||
| Output Conduit | 25.4mm | |||
| PV Input Conduit | 25.4mm | |||
| BAT Input Conduit | 34.5mm | |||
| Operating Temperature Range | -25 ~ +60°C | |||
| Relative Humidity | 0-95% | |||
| Operating Altitude | 0 ~ 4000m | |||
| Ingress Dziviriro | IP65/NEMA 3R | |||
| Kurema | 48kg | |||
| Saizi (Kufara*Kureba*Kudzika) | 450mm x 820mm x 261mm | |||
| Kutonhodza | Air Cooling | |||
| Noise Emission | <38dB | |||
| Display | LCD | |||
| Kukurukurirana neBMS/Meta/EMS | CAN, RS485 | |||
| Inotsigirwa Kukurukurirana Interface | RS485, WLAN, 4G (kusarudza) | |||
| Kuzvidyira paHusiku | <25W | |||
| Safety | UL1741SA sarudzo dzese , UL1699B, CSA 22.2 | |||
| EMC | FCC Chikamu 15 KirasiB | |||
| Grid Connection Standards | IEEE 1547, IEEE 2030.5, Hawaii Rule 14H, Rule 21 Chikamu I,II,III | |||
| Object | Tsanangudzo |
| 01 | BAT inpu/BAT kubuda |
| 02 | WIFI |
| 03 | Communication Pot |
| 04 | CTL 2 |
| 05 | CTL 1 |
| 06 | Load 1 |
| 07 | Ground |
| 08 | PV kuisa |
| 09 | PV yakabuda |
| 10 | Jenareta |
| 11 | Grid |
| 12 | Load 2 |
