AM4800 4.8KWH 48V 100AH Rack-Mounted Lithium Ion Low Voltage Solar Battery
AM4800 4.8kwh 48V 100AH Lithium Ion Low Voltage Solar Battery
Product Description
AM4800 is a high-performance, low-voltage energy storage solution designed for residential l applications. With its 4.8kwh capacity and 100AH rating at 48V, it offers efficient and reliable energy storage, providing a backup power supply and supporting hybrid inverter or off-grid inverter.
Leading Features
-
01
Long service life
Maximum service life with more than 6000 times.
-
02
LFP Prismatic Cell
Current interrupt Device (CID) helps pressure relief and ensures safe and detect controllable aluminum shells is welded to ensure sealing.
-
03
48V low-voltage
Support 16 sets parallel connection.
-
04
BMS
Real-time control and accurate monitor in single cell voltage, current and temperature, ensure battery safety.
Solar Hybrid Inverter Application
System Connection
Amensolar’s low-voltage battery utilizes lithium iron phosphate as its positive electrode material, and its durable square aluminum shell cell design ensures stability. Employed in tandem with a solar inverter, it efficiently transforms solar energy, ensuring a steady power supply for electrical needs and loads.
Certificates
Case Presentation
Package
Careful packaging:
We focus on packaging quality, using tough cartons and foam to protect products in transit, with clear usage instructions.
Secure shipping:
We partner with trusted logistics providers, ensuring products are well-protected.
| Item | AM4800 |
| Battery Type | LifePo4 |
| Mount Type | Rack Mounted |
| Nominal Voltage (V) | 48 |
| Capacity(Ah) | 100 |
| Nominal Energy (KWh) | 4.8 |
| Operating Voltage(V) | 42~54.75 |
| Max Charge Current(A) | 100 |
| charging Current(A) | 80 |
| Max Discharge Current(A) | 100 |
| discharging current(A) | 80 |
| charging Temperature | 0℃~+55℃ |
| Discharging Temperature | -20℃~+55℃ |
| Relative Humidity | 5% – 95% |
| Dimension(L*W*H mm) | 482*568.5* 138.5 |
| Weight(KG) | 46 |
| Communication | CAN, RS485 |
| Enclosure Protection Rating | IP21 |
| Cooling Type | Natural Cooling |
| Cycles Life | ≥6000 |
| Recommend DOD | 90% |
| Design Life | 20+ Years (25℃@77。F) |
| Safety Standard | CE/UN38.3 |
| Max. Pieces of Parallel | 16 |
| No. | Name | Label | Function Description |
| 1 | Grounding | Ground wire | |
| 2 | Power button | ON/OFF | Power button. When switched to ” ON” , the system can be activated by the ” SW” key or external power supply; when switched to ” OFF” , the system is turned off. |
| 3 | Capacity indicator | SOC | There are 4 green lights to show battery capacity, and each green light represents 25% of SOC. |
| 4 | Alarm indicator | ALM | Red light. The indicator light flashes when alarming. When protected, the indicator light will stay on. |
| 5 | Running lights | RUN | Green light. In standby, the indicator light flashes. When charging, the indicator light is always on. The indicator flashes when discharging. |
| 6 | DIP switch | ADDR | Set address |
| 7 | External communication port | CAN | Communication with external devices |
| 8 | External communication port | RS485 | Communication with external devices |
| 9 | External communication port | RS485 | Communication with external devices |
| 10 | Reset button | Reset | Restart battery |
| 11 | Negative interface | “ – ” | Negative interface |
| 12 | Negative interface | “ -” | Negative interface |
| 13 | Positive interface | “ + ” | Positive interface |
| 14 | Positive interface | “ + ” | Positive interface |
| 15 | Hanging ear | / | Used to fix the battery box (two on the front panel and three on both sides) |
